PoE camera power: ports, budgets and installation fit

Choose active PoE equipment by the camera standard, each port limit and the shared budget. An Ethernet connector alone does not establish PoE, and the switch port count does not tell you how many ports supply power.

CameraViewer editorial · Editorial review October 14, 2026 · Documentation-led buying guide

Write down the complete cable route

A PoE installation has a camera, a power-sourcing port, the network path back to the router and the cable connections between them. Start with one camera position. Record whether the cable and each connection will be indoors, outdoors or in a damp enclosure. The camera's weather rating does not protect an exposed connector, injector or indoor switch.

The RLC-810A specifies active 48 V IEEE 802.3af power or a separate DC supply. The Duo 2 PoE also specifies active 802.3af. Match the standard in the exact camera documentation; do not substitute a passive injector because its connector fits.

Separate physical ports from powered ports

The inspected manufacturer pages describe these configurations. Hardware revisions matter, so compare the version on the actual listing and unit before treating a number as current.

Device	Inspected powered-port arrangement	Published limit	Scope to preserve
TP-Link TL-SG1005P	Four PoE ports, five network ports total	15.4 W per port; 65 W shared on the inspected US page	The page also mentions af/at devices; it does not justify silently replacing the stated port rating with 30 W
TP-Link TL-SG1008P	Four PoE ports, eight network ports total	15.4 W per port; 55 W shared on the inspected US page	Eight network ports does not mean eight powered cameras
TP-Link POE150S / former TL-POE150S URL	One injector route	15.4 W maximum; 802.3af	The old URL redirects to current Omada documentation; match the supplied revision

Read the five-port switch source, eight-port source and injector source. These are examples for checking requirements, not verified interchangeable shopping offers.

Check two budgets, not just one sum

Each camera must fit its own port's supported standard and delivered-power limit. All powered cameras together must also fit the switch's shared budget. Use the equipment maker's specified power requirements, including accessories, rather than average use observed on a quiet day. Power available at a source port and power delivered to a device can differ because the cable consumes some power.

The RLC-810A source lists consumption below 12 W; Duo 2 PoE lists below 15 W. Their simple sum is below 27 W. That arithmetic is only a first screen. It does not certify the complete installation against a 15.4 W source-port rating, cable losses, startup behavior or an exact switch revision. Confirm each camera's explicit 802.3af compatibility and the selected switch documentation before using the pair.

A missing camera consumption field should remain missing. Do not fill it with a guessed value and produce a reassuring total. Stop the sizing decision until the manufacturer supplies the requirement. This page provides a requirements table rather than a calculator with invented default loads.

Match cable and mount separately

Use a cable and connection system rated for the route. Check the camera manufacturer's installation instructions for waterproof couplers, strain relief, mounting orientation and screws. Do not infer a mount fits because the brand matches; compare the exact camera and mount model or manufacturer fit list.

Keep an injector or switch inside its own specified operating environment. If the cable route needs building work, grounding or lightning protection, have the installer resolve those requirements. A listed camera weather rating does not settle the rest of that work.

Test the network and video after power is established

Confirm the camera starts, receives the intended network address and exposes the documented local endpoint. Then inspect the selected codec. PoE success does not establish video decoding, audio, camera controls or recording in another app. The outdoor buying guide, Reolink setup guide and recording routes cover those next decisions.
